Description Of Vertical Powder Coating Line

This red automatic powder coating line was designed for the customer who supply the powder coating services to the others.

The working process for this line is, loading --- spray type pre-treatment --- water drying --- automatic powder coating --- automatic powder curing --- cooling --- unloading.

Automatic chain system: 2 sets driving system and 2 tensioning system. Chain can bearing 100kg/single point. Chain speed, 2.5m/min (you can adjust according your need). Total length for the chain, 295m

Pre-treatment system: Stainless steel spray type.

Steps are, pre-degreasing --- degreasing --- water washing 1 --- pure water washing 2 --- nano ceremic --- water washing 1 --- pure water washing 2

Automatic water drying oven: this oven only have the temperature for 120 Celsius.

Automatic powder coating booth: the cyclone system will help you to recycle the 99.5% of the powder, and the material is PP type, it can allow you to change the color just in 15min. And the reciprocator and automatic gun will help you to do the automatic powder coating. There will be also 2 manual working station to making up the powder coating for some dead corner.

Automatic powder curing oven: powder curing oven have the temperature for 180~230 Celsius. The work piece can curing 20~30min just according your need.

Or

Quick detail Of Vertical Powder Coating Line

Specification Of Vertical Powder Coating Line

    Foshan ABD Equipment Co., Ltd was founded in 2003. Since we started, ABD has been doing great work on design, manufacturing, and installation of aluminum surface treatment equipment, including electrostatic powder coating lines, anodizing and coloring lines as well as fluorocarbon liquid painting lines. We will create customized designs and provide the vertical and horizontal types for each customer based on their individual needs.

    At ABD, we employ experts in mechanical design, electrical engineering, Research and Development, as well as providing exceptional after-sales associates. Our manufacturing divisions have many skilled production workers totally more than 200 employees in the company. Every year, ABD continually invests in the latest machines to improve the quality of our products like automatic laser cutting machines and welding robots, sandblasting technologies and an environmentally friendly liquid painting room. Therefore, with all these efforts, our production lines carry more than 20 patents and CE certifications. With almost 20 years of experience and feedback from our customers, ABD has provided more than 600 highly efficient lines all over the world.
